[System Synopsis]
EOPS: Ethernet Onepass Printer Engine System
(1) Up to10 Gigabit Ethernet network architecture, greatly improve the efficiency of data transmission;
(2) Distributed architecture, unlimited print heads quantity in system;
(3) Highly modular designed, easily combined with third party feeding system;
(4) Convenient adjustment of mechanical calibration, easy to deal with roll and sheet media;
(5) The operation and maintenance of the printer are simple and convenient;
(6) DOD piezo electric grayscale print heads, industrial level standard are more reliable.
[Print Head Synopsis]
The StarFire SG1024 printhead is a breakout inkjet innovation for high performance printing and decorative applications. It is purpose-built for today’s demanding high-speed scanning and single-pass
industrial systems designs. It is an easy to integrate, high performance, drop-on-demand printhead for
single-color operation at resolutions up to 400 dpi, two color operation at resolution up to 200 dpi. A robust and repairable construction makes it ideal for Textile, Wide Format and Commercial Printing and Decorating.
[System Wiring]
[Application]
Label printing; Barcode Printing and etc.
