[System Synopsis]
EOPS: Ethernet Onepass Printer Engine System
(1) Up to10 Gigabit Ethernet network architecture, greatly improve the efficiency of data transmission;
(2) Distributed architecture, unlimited print heads quantity in system;
(3) Highly modular designed, easily combined with third party feeding system;
(4) Convenient adjustment of mechanical calibration, easy to deal with roll and sheet media;
(5) The operation and maintenance of the printer are simple and convenient;
(6) DOD piezo electric grayscale print heads, industrial level standard are more reliable.
[Print Head Synopsis]
The Xaar 1003 AMp is perfect for very small drop fluid deposition on an industrial scale and is capable of consistently jetting droplets as small as 1 pL for the production of fine features, patterns and coatings. The combination of highly accurate, very small drops and unrivalled reliability enables the industrialisation of advanced manufacturing processes in sectors such as display, PCB, semiconductors and photovoltaics.
Many applications require tight regulation of coating thicknesses, precise patterns and management of substrate surface characteristics. The Xaar 1003 AMp combines highly accurate drop placement, consistent drop volume and high frequency jetting with variable drop size capability to deliver the precise fluid control essential for these processes.
[System Wiring]
[Application]
Label printing; Barcode Printing and etc.
